How to Fix Your Imperia Pasta Machine: A Complete DIY Guide 2026

The classic Imperia pasta machine is a kitchen workhorse that has remained virtually unchanged for decades. Built to last, these sturdy manual pasta makers are worth repairing rather than replacing. If your machine has become stiff or jammed, this guide will walk you through the restoration process step by step.

Why Repair Your Imperia Pasta Machine?

Even the most robust hand-crank pasta makers have parts that wear out over time. Intensive use of the Imperia pasta machine and constant rotation of the two rollers can make operation jerky or even impossible. When this happens, inspecting the gears is the only real solution. Disassembly is straightforward, as the two shaped sheet metal side covers are each held on by a single screw.

Locating the Hidden Gears

Contrary to what you might expect, there are no visible gears on either the crank side or the knob side that adjusts the dough thickness. The gear wheels you need to access are hidden inside a small housing within the side panels. This means you must completely disassemble the heart of the pasta machine — including the scrapers that press against the bottom of the rollers to prevent dough from sticking during thinning.

Assessing the Damage

Once exposed, the roller drive gears often show significant wear. The contact surfaces of the teeth may be seriously abraded, and in some cases, a gear might even be broken in half. Unless you're a skilled welder, repair is not possible — replacement is the only option. In this project, a gear from another discarded machine was adapted, but since the Imperia design hasn't changed in decades, finding original spare parts is entirely feasible. When reassembling with partially worn gears, mount them "upside down" to use the unworn tooth surfaces, and lubricate everything with a little Vaseline grease for smooth operation.

Step 1: Remove the Thickness Adjustment Knob

Begin by unscrewing the knob that controls the roller gap. This will give you access to the side panel screws.

Step 2: Disassemble the Side Panels

Remove the single screw on each side to take off the shaped metal covers. Keep these parts organized — you can store small components in a home improvement organizer to avoid losing them.

Step 3: Extract the Gear Housing

Carefully pull out the internal gear casing. You may need to gently pry it free if it's stuck due to old grease or residue.

Step 4: Inspect and Replace Gears

Check each gear for broken teeth or excessive wear. If replacement is needed, source original Imperia parts or adapt compatible gears. For a smooth workspace, consider a sturdy work surface for your repair project.

Step 5: Reassemble the Scrapers, Locking Rods, and Knob

Reinstall the scrapers that keep dough from sticking, the locking rods, and finally the thickness adjustment knob. Test the mechanism by turning the crank — it should rotate freely and evenly.

Tools and Materials You'll Need

• Screwdrivers (flathead and Phillips)
• Replacement gears (original Imperia or compatible)
• Vaseline grease or food-safe lubricant
• Clean rags for wiping old grease
• A small tool kit for precision work

Tips for Long-Lasting Performance

• Always clean and dry the rollers after each use to prevent rust.
• Lubricate the gears annually with food-grade grease.
• Store your machine in a dry place — a storage bench can keep it protected and organized.
• If you frequently make pasta, consider pairing your machine with a kitchen island or cart for dedicated prep space.

Frequently Asked Questions

Can I use any lubricant on my Imperia pasta machine?

Only use food-safe lubricants like Vaseline or white mineral oil. Avoid WD-40 or standard greases, as they can contaminate your pasta.

Where can I find replacement gears for an Imperia machine?

Check online marketplaces, specialty kitchen stores, or salvage shops. Because the design is decades-old, many parts are interchangeable between models.

Why does my pasta machine keep jamming?

Jamming is often caused by worn gears, dried dough residue on the rollers, or improper dough hydration. Clean the rollers thoroughly and inspect the gears if the problem persists.

Is it worth repairing an old Imperia machine?

Absolutely. These machines are built from solid metal and can last a lifetime with proper care. Repairing is often cheaper and more sustainable than buying a new plastic-based model.

Can I adjust the roller gap without disassembling the machine?

Yes, the knob on the side adjusts the gap. But if the mechanism is stuck, internal gear issues may be the cause, requiring disassembly.
