Triangular chicken coop construction project 2026

Triangular chicken coop construction project, building a chicken coop is a very fun job to do during the weekend. Having chickens not only allows you to enjoy fresh eggs daily, but it is also a great way to dispose of household waste.

Chicken coop construction project

Special attention points
Chickens need a place to shelter from the cold and rain and sleep safely at night. Medium-sized breeds need 1.5 m2 of space per hen, while half that area is enough for dwarf breeds. Make sure hangers are the right size and shape.

The chicken coop must be well ventilated. In addition to a warm place to sleep, there should also be an outside space for the chickens to scratch the ground.

Projects: Similar ideas

1#

2#

3#

4#

5#

6#

Materials needed:

Here we show certain dimensions as a guide. You can change the length, width and height in proportion according to your needs.

Structure:

– 2 long bars of 44 × 44 mm and about 400 cm long
– 4 crossbars measuring 44 × 44 mm and about 160 cm long

A-shaped frames:

– 6 bars for the raised pieces, each 28 × 58 mm and about 60 cm long
– 1 crossbar measuring 44 × 44 mm and about 400 cm long for the roof ridge
– 3 cross pieces, each 28 x 58 mm and about 76 cm long

Soil:

– Formwork plywood 12 mm thick and about 70 x 200 cm in surface

Support bars:

– 2 long bars, each 28 x 58 mm and about 420 cm long
– 2 transversal pieces, each 95 cm long

Side walls:

– 6 boards measuring 165 x 22 mm and about 200 cm long for the closed sides
– 6 boards measuring 165 x 22 mm and about 200 cm long for the open sides
– 75 x 20 mm bars for the side opening: 3 about 130 cm long and 2 about 170 cm long

Rear wall: formwork plywood 12 mm thick and about 156 cm per side, sawn into a triangle shape
Steps: board 30 cm wide and about 125 cm long, with small crossbars as steps
Wire mesh 200 cm x 800 cm
Wire mesh strips: if necessary, finish the wire mesh with 50 x 10 mm wooden slats
Nest bars: 12 mm formwork plywood on 5 x 4 cm sticks

1 Construction diagram

This A-shaped chicken coop can accommodate 3 or 4 chickens. The length needed will depend on the number of chickens you want to have. Use a weather-resistant outdoor wooden door, preferably of FSC-certified quality. These woods are impregnated with an environmentally safe material, so it is not necessary to apply any additional treatment

2 Basic structure

The first step is to assemble the basic structure of the chicken coop. Make the structure as shown in the drawing, with 44 x 44 mm bars. To prevent the wood from splintering when screwing the pieces together, it is best to pre-drill the holes for the screws.

3 A-shaped supports

LoA-shaped brackets are basically triangular. Saw the base of the triangle at 60° and the top at 30°. Next, join the bottom angles of the bars using galvanized screws about 65mm long.

Attach the A-shaped brackets to the upper crossbar

Continue to structure the chicken coop by attaching the three A-brackets to the top crossbar. Make sure the triangles line up well. Before attaching the top rail, use a spirit level to check whether the A-brackets are vertical.

5 Cross pieces

Next, screw the center cross pieces (about 30 inches long) to the sides of the A-brackets. Use a spirit level to check if the cross pieces are straight, as they will need to support the floor of the chicken coop.

6 Support beams

Now we are going to place the long bars, which also serve as carrying handles on the front and back. When placing the long bars, use a spirit level to ensure that the entire structure is perfectly horizontal. Then place the horizontal supports on both sides.

7 Floor

Saw a piece of plywood (or, better yet, formwork plywood) to the appropriate size and secure it with screws to the long bars and cross pieces.

8 Rear part of the roof

Next comes the back section of the chicken coop roof. It is made up of 165 x 22 mm slats that overlap each other.

9 Front roof

The front part of the chicken coop roof also serves as an entrance. First, attach a slat to the top using screws. Next, place a spacer block underneath so you can slide the roof panel under it. This way the panel will remain firmly fixed and no rainwater will enter. For the movable roof panel, make a frame with 75 x 20 cm bars and then fix the overlapping horizontal slats with screws. If necessary, you can secure the underside of the roof using a rotating wooden block or bolt.

10 Rear part

Use a sharp circular saw or hand saw. Saw the back wall into a triangular shape the same as that of the A-frame bracket and secure it with screws.

11 Use the back wall as a door

You can use the back panel as an alternative chicken coop entrance. To do this, mount two hinges at the bottom. Then permanently attach the front of the roof with screws.

12 Steps

To make it easier for chickens to enter and exit the coop, create simple steps by securing cross slats with screws. Don't forget to pre-drill the holes to prevent the wood from splintering. Screw the steps to the cross pieces of the base frame.

13 Hangers

The diameter of the perches will depend on the size of your chickens. Place the perches about 15cm off the ground. Avoid using round hangers. Chickens have a hard time sitting on them safely. They should be square or oval in cross section. Each hanger should be on average about 5.5cm wide and 4cm thick. Place the widest side of the perch horizontally so that the chickens have good support.

Nest
Every chicken coop needs a nesting box. A 30 x 30 cm nest box with a height of about 40 cm is more than enough. Put a layer of gravel inside the nest box. This way the hens will be able to scrape the calcium from the gravel, a component they need for the shell of their eggs.

14 Apply metal fabric

Place the metal clothca on the chicken coop and secure it with staples or tacks. Then, as a finishing touch, place strips on the wire mesh so as not to hurt yourself on the edges. You can also attach the wire mesh before the support bars, but this will make it more difficult to position the ramp.

15 Material to cover the ground

This chicken coop is very easy to move from one part of the garden to another. This way the earth will always be cleaner.

The best thing to cover the floor of the chicken coop is to use wood chips, clean sand or a mixture of both materials. If you prefer, you can use straw, but in this case make sure it is always well aerated.
